Astronomik OIII 6 nm Filter 50 mm, unmounted, protective ring

Codice articolo: 8H00NF

The Astronomik [O III] filter is a super narrow band line filter for astro photography.

♦ 90% guaranteed transmission at 501 nm [[O III] line]

♦ 95% typical transmission at 501 nm [[O III] line]

♦ FWHM 6 nm

♦ Blocks UV and IR completely, necessary for digital photography

♦ Main operational use: planetary nebulae & supernova remnants

♦ Parfocal with other Astronomik filters

♦ No moisture-sensitivity, no aging, and totally scratch-proof

♦ Substrate optically polished

♦ Blackened edge

♦ 10 years warranty by manufacturer

♦ Connection: round filter 50 mm, unmounted, protective ring

The Astronomik [O III] filter is a super-narrow band emission line filter for astro photography from observation sites with heavy light pollution and from dark sites as well.

The contrast between an object glowing at 501 nm and the background is increased enormously!

Due to the combination of the narrow bandwidth of 6 nm and the high transmission of typically 95%, the filter gives you an enormous contrast boost, as all unwanted light is blocked from UV up to the IR. This results in an extremely dark background.

The FWHM of 6 nm is matched to give you optimal performance with CCD and CMOS sensors with a very low dark current! The 6 nm filter is the best choice if you are observing from a heavily light polluted site or if you are imaging faint objects in starcrowded regions of the Milky Way.

Due to the MFR coating technique you may use one single filter on all instruments up to f/4 without a significant reduction in performance.

Imaging with narrow band emission line filters

If you have to observe from light polluted sites (like most of us ...), imaging with narrow-band emission line filters is the best way to take great images, as all kind of light pollution can be blocked very effective! Normaly an H-alpha filter should be your first step into this amazing field of astrophotography! With a narrow band H-alpha filter you will be able to take deep and contrasty images even wih very heavy light pollution or with the full moon high up in the sky! If you look at other astrophotos, an H-alpha is the best choice for all nebulas glowing red! An [O III] filter expands your imaging possibilities, as you are able to image all greenish/blueish structures. Planetary nebulas and star forming regions are great targets! The [S II] filters completes your HSO-set of filters. With these three filters you are able to process your images like the ones from the Hubble space telescope!

The h-beta filter is not available in a 6 nm version, as this filter has nearly no meaningfull application. it is better to use the 6 nm H-alpha filter.

Operation of the filter:

The filter blocks all unwanted light from artifical light-pollution, natural airglow and moonlight. Especially light from high- and low-pressure sodium and mercury lights and all lines of natural airglow are 100% blocked. The filter increases the contrast between the sky-background and objects glowing at the [O III] line at 501 nm.

Other uses:

Using the OIII filter together with H-alpha and SII filters you make produce false-color emission line images (HSO) in the same way as the Hubble-Space telescope. This is possible even from heavyly light polluted sites!

Alternatives:

The lower priced 12 nm filters are the right choice for you if you own a typical DSLR or a astro camera with a high dark current! The 12 nm filters should be the fist choice for cameras with an integrated guiding sensor, as you will have about twice as much stars compared to the 6 nm filter.

Note on the protective ring:

Astronomik delivers the round filters from 31 mm diameter with a protective ring at the edge. The corresponding declarations of the manufacturer are available for download as PDF.

Filter transmission curve:

♦ The horizontal axis is the wavelength in nanometers (nm). 480 nm is light blue, at 520 nm the human eye senses green.
♦ The transmission in % is plotted on the vertical axis.
♦ The green line shows the transmission of the filter.
♦ The most important emission lines from nebulas are shown in orange. The most important lines are from ionized Hydrogen (H-beta) and double ionized oyxgen ([O III]). The square brackets indicate that these lines are forbidden.

Specifiche tecniche:

Guaranteed transmission at 501 nm [[O III] line]: 90%
Typical transmission at 501 nm [[O III] line]: 95%
FWHM: 6 nm
UV and IR blocking: yes
Anti reflective coating: No moisture-sensitivity, no aging, and totally scratch-proof
Carrier material: optically polished substrate
Parfocal: With all other Astronomik filters
Glass thickness: 1 mm
